NASA’s NICER Finds X-ray Boosts in the Crab Pulsar’s Radio Bursts

  • Released Thursday, April 8, 2021

Scientists using data from NASA’s Neutron star Interior Composition Explorer (NICER) telescope on the International Space Station have discovered X-ray surges accompanying radio bursts from the pulsar in the Crab Nebula. The finding shows that these bursts, called giant radio pulses, release far more energy than previously suspected.

A pulsar is a type of rapidly spinning neutron star, the crushed, city-sized core of a star that exploded as a supernova. A young, isolated neutron star can spin dozens of times each second, and its whirling magnetic field powers beams of radio waves, visible light, X-rays, and gamma rays. If these beams sweep past Earth, astronomers observe clock-like pulses of emission and classify the object as a pulsar.

Located about 6,500 light-years away in the constellation Taurus, the Crab Nebula and its pulsar formed in a supernova explosion. The neutron star spins 30 times each second, and at X-ray and radio wavelengths it is among the brightest pulsars in the sky.

Out of more than 2,800 pulsars cataloged, the Crab pulsar is one of only a few that emit giant radio pulses, which occur sporadically and can be hundreds to thousands of times brighter than the regular pulses. And after decades of observations, only the Crab has been shown to enhance its giant radio pulses with emission from other parts of the spectrum.

Previously seen in visible light, these enhancements now have been detected in X-rays for the first time. Between August 2017 and August 2019, researchers used NICER to repeatedly observe the Crab pulsar in X-rays. While NICER was watching, the team also studied the object using at least one of two ground-based radio telescopes in Japan.

The team combined all of the X-ray data that coincided with giant radio pulses, revealing an X-ray boost of about 4% that occurred in synch with them. It’s remarkably similar to the 3% rise in visible light associated with the phenomenon, discovered in 2003. The researchers say that the total emitted energy associated with a giant pulse is dozens to hundreds of times higher than previously estimated from the radio and optical data alone.

The enhancements suggest that giant pulses are a manifestation of underlying processes that produce emission spanning the electromagnetic spectrum, from radio to X-rays. And because X-rays pack millions of times the punch of radio waves, even a modest increase represents a large energy contribution. The researchers conclude that the total emitted energy associated with a giant pulse is dozens to hundreds of times higher than previously estimated from the radio and optical data alone.

X-rays detected by NASA’s Neutron star Interior Composition Explorer (NICER) on the International Space Station reveal a high-energy connection to the Crab pulsar’s giant radio pulses. Between 2017 and 2019, NICER and radio telescopes in Japan studied the pulsar at the same time. In this visualization, representing just 13 minutes of NICER observations, millions of X-rays are plotted relative to the pulsar’s rotational phase, which is centered on the strongest radio emission. For clarity, two full rotations are shown. As the pulsar beams sweep across our line of sight, they produce two peaks for each rotation, with the brighter one associated with greater numbers of giant radio pulses. For the first time, NICER data show a slight increase in X-ray emission associated with these events. Credit: NASA’s Goddard Space Flight Center/Enoto et al. 2021

X-rays detected by NASA’s Neutron star Interior Composition Explorer (NICER) on the International Space Station reveal a high-energy connection to the Crab pulsar’s giant radio pulses. Between 2017 and 2019, NICER and radio telescopes in Japan studied the pulsar at the same time. In this visualization, representing just 13 minutes of NICER observations, millions of X-rays are plotted relative to the pulsar’s rotational phase, which is centered on the strongest radio emission. For clarity, two full rotations are shown. As the pulsar beams sweep across our line of sight, they produce two peaks for each rotation, with the brighter one associated with greater numbers of giant radio pulses. For the first time, NICER data show a slight increase in X-ray emission associated with these events.

Credit: NASA’s Goddard Space Flight Center/Enoto et al. 2021

The Crab Nebula is supernova remnant, expanding debris from the explosion of a star many times the Sun's mass. This image combines data from NASA's Chandra, Hubble, and Spitzer space telescopes to explore the cloud in X-ray (blue-purple), visible (green), and infrared (red) light. The Crab pulsar, a neutron star spinning 30 times a second, is the bright spot near the center. The Crab Nebula is located 6,500 light-years away in the constellation Taurus.Credit: NASA, X-ray: CXC, J. Hester (ASU) et al.; optical: ESA, J. Hester and A. Loll (ASU); infrared: JPL-Caltech, R. Gehrz (U. Minn)

The Crab Nebula is supernova remnant, expanding debris from the explosion of a star many times the Sun's mass. This image combines data from NASA's Chandra, Hubble, and Spitzer space telescopes to explore the cloud in X-ray (blue-purple), visible (green), and infrared (red) light. The Crab pulsar, a neutron star spinning 30 times a second, is the bright spot near the center. The Crab Nebula is located 6,500 light-years away in the constellation Taurus.

Credit: NASA, X-ray: CXC, J. Hester (ASU) et al.; optical: ESA, J. Hester and A. Loll (ASU); infrared: JPL-Caltech, R. Gehrz (U. Minn)
