Sea Surface Temperature Anomalies and Patterns of Global Disease Outbreaks: 2009-2018 (4K version)

  • Released Thursday, January 9, 2020
View full credits

This webpage provides the 4K version of: Sea Surface Temperature anomalies and patterns of Global Disease Outbreaks: 2009-2018 (updated), released on January 6, 2020.

Content has been created for 4K display systems that can handle finer resolution and details. It is recommended to use content from this version for HD (1920x1080) and lower resolutions.




This visualization shows the variability in global sea surface temperature anomalies, the associated ENSO index timeline and locations of infectious disease outbreaks over the global land surface. Content is available in 4K resolution.

The content available in this group of frames and movies does not include the label Strong El Niño Period in the ENSO index timeline for the highlighted period 2015-2016.



The El Niño-Southern Oscillation (ENSO) phenomenon is an irregularly recurring climate pattern characterized by warmer (El Niño) and colder (La Niña) than usual ocean temperatures in the equatorial Pacific, which creates a ripple effect of anticipated weather changes in far-spread regions on Earth. Weather changes associated with the El Niño-Southern Oscillation phenomenon result in rainfall, temperature and environmental anomaly conditions worldwide that directly favor outbreaks of infectious diseases of public health concern.



During the last 20 years NASA scientist Dr. Assaf Anyamba and colleagues have been studying interannual climate variability patterns associated with El Niño by monitoring various climate datasets, among them land surface temperature and vegetation data from the Advanced High Resolution Radiometer (AVHRR) on board NOAA POES satelittes, the Moderate Resolution Imaging Spectroradiometer aboard NASA's Terra and Aqua satellites, and Sea Surface Temperature and precipitation anomaly datasets from NASA and the National Oceanic and Atmospheric Administration (NOAA). At the same time, the science team has been collecting, cataloguing and analyzing patterns of disease outbreaks worldwide.



Dr. Anyamba and colleagues conducted a scientific study - the first one to comprehensively assess the public health impacts of the major climate event on a global scale - that was published in the journal Nature Scientific Reports, with the title Global Disease Outbreaks Associated with the 2015-2016 El Niño event and is open access available. According to the study, the 2015-2016 El Niño event brought weather conditions that triggered disease outbreaks in ENSO teleconnected regions throughout the world.



The visualization showcases a global flat map with monthly Sea Surface Temperature (SST) anomaly data over water, the locations of Global Disease Outbreaks of ten infectious diseases on land, along with a timeline plot of the ENSO Index (Niño 3.4 Index region SST anomaly) for the period 2009-2018 on the bottom. The Nino 3.4 Index region SST with extents (5N-5S, 120W-170W) is the box region, highlighted on the Pacific Ocean.



During ENSO events, SST anomalies influence the nature and patterns of rainfall, vegetation and land surface temperatures on the land surface, which in turn influence the disease outbreaks that are mapped on a global scale. The 11 diseases mapped on this visualization are: chinkungunya, cholera, dengue virus, hantavirus, respiratory illness, Rift Valley fever, Ross River virus, St. Louis encephalitis, tularemia and zika virus/



During the 2015-2016 El Nino event, which is manifested in the visualization with increased sea surface temperature anomaly (reds in Niño 3.4 Index Region), changes in precipitation, land surface temperatures and vegetation created and facilitated conditions for transmission of diseases, resulting in an uptick in reported cases for plague and hantavirus in Colorado and New Mexico (in 2015), cholera in East Africa’s Tanzania (during 2015 and 2016), and dengue fever in Brazil and Southeast Asia (during 2015), among others.



According to the study, El Niño-driven increase in rainfall and milder temperatures over the American Southwest, spurred vegetative growth, providing more food for rodents that carry hantavirus. A resulting rodent population explosion put them in more frequent contact with humans, who contract the potentially fatal disease mostly through rodent fecal or urine contamination. As their rodent hosts proliferated, so did plague-carrying fleas.



Regarding dengue outbreaks, the strong El Niño period produced higher than normal land surface temperatures and therefore drier habitats, which drew mosquitoes into populated, urban areas where there are open water storage containers providing ideal habitats for mosquito production. In addition, the higher the normal temperatures increase the maturation time of larvae to adult mosquitos and also induce frequent blood feeding/biting by mosquito vectors resulting in increased number of disease cases. The following 3 data driven visualizations demonstrate the complex relationships between the El Niño event in 2015-2016 and disease outbreaks of dengue in the South East Asia region:





The impact of ENSO induced anomalous rainfall is clearly illustrated by outbreak patterns of Rift Valley fever (RVF) in East and South Africa. During ENSO events, Eastern Africa (El Niño) and South Africa (La Niña) receive persistent and above normal rainfall, which floods habitats of RVF mosquito vectors triggering hatching of RVF virus infected eggs. The above-normal rainfall is followed by an increase in vegetation creating appropriate habitats for the mosquito vectors setting the stage for RVF outbreak activity, which in simple terms means an uptick in mosquito populations that cause infections of domestic livestock and human populations. The results is the sea-saw pattern exhibited by the ENSO events drives patterns of disease outbreaks in different regions around the world. To learn more about the relationship between ENSO and Rift Valley fever outbreaks in the region of South Africa, please refer to:





The strong relationship between ENSO events (i.e El Niño, La Niña) and disease outbreaks underscores the importance of seasonal forecasts. Since disease outbreaks typically manifest 2-3 months after the start of ENSO events, early and regular climate monitoring, paired with the use of monthly and seasonal climate forecasts become significant tools for disease control and prevention. Findings of the scientific study suggest that by monitoring monthly climate datasets, country public health agencies and organizations such as the United Nations' World Health Organization and Food and Agriculture Organizations, can utilize early warning forecasts to undertake preventive measures to minimize the spread of ecologically coupled diseases.






Data Sources:



  • Sea Surface Temperature (SST) data: The SST known as the NOAA OI.v2 SST monthly fields are derived by a linear interpolation of the weekly optimum interpolation (OI) version 2 fields to daily fields then averaging the daily values over a month. The analysis uses in situ and satellite SST's plus SST's simulated by sea-ice cover. Before the analysis is computed, the satellite data is adjusted for biases using the method of Reynolds (1988) and Reynolds and Marsico (1993). The SST dataset is available here


  • Disease Outbreak data were collected from the Program for Monitoring Emerging Diseases (ProMED), the Pan-American Health Organization (PAHO) online country reports, weekly summaries of disease outbreaks reported by the Department of Defense Armed Forces Health Surveillance Branch and from the World Organisation for Animal Health/Organisation mondiale de la santé animale (OIE).


  • SST ENSO index (Niño 3.4) for the period 2009-2018 is obtained from the NOAA National Center for Climate Prediction online archives. The warm (El Niño) and cold (La Niña) periods of ENSO events were determined using the Oceanic Niño Index (ONI) threshold of +/- 0.5°C based on centered 30-year base periods updated every 5 years. The ONI is a 3-month running mean of Extended Reconstructed Sea Surface Temperature (ERSST) Version 4 (v4) SST anomalies in the Niño 3.4 region (5 N-5 S, 120W-170W).






Supported with funding from the Defense Threat Reduction Agency's (DTRA) Joint Science and Technology Office for Chemical and Biological Defense (JSTO-CBD) Biosurveillance Ecosystem (BSVE) Program (HDTRA1-16-C-0045) and the Defense Health Agency-Armed Forces Health Surveillance Branch (AFHSB) Global Emerging Infections Surveillance and Response System (GEIS) under Project # P0072_19_NS.



This rest of this webpage provides frames, movies, colorbar information and layers associated with the development of this data visualization.

This visualization captures monthly Sea Surface Temperature (SST) anomalies around the world from 2009-2018, along with locations of global disease outbreaks. This version does not include the timeline of the Niño 3.4 index. Frames are available in 4K resolution.

Frames of monthly Sea Surface Temperature Anomalies and locations of Global Disease Outbreaks for the period of 2009-2018. Frames are provided with alpha channel.

Frames of monthly Sea Surface Temperature Anomalies and locations of Global Disease Outbreaks for the period of 2009-2018. Frames are provided with alpha channel.

Still image of the global diseases panel and their associated symbols (provided with transparency). The 11 infectious diseases visualized are: Chinkungunya, Cholera, Dengue virusl, Hantavirus, Plague, Respiratory Illness, Rift Valley fever, Ross River virus, St. Louis Encephalitis, Tularemia and Zika virus.

Still image of the global diseases panel and their associated symbols (provided with transparency). The 11 infectious diseases visualized are: Chinkungunya, Cholera, Dengue virusl, Hantavirus, Plague, Respiratory Illness, Rift Valley fever, Ross River virus, St. Louis Encephalitis, Tularemia and Zika virus.

Still image of latitude axes with equator line, provided with transparency. This still image can be overlaid on top of the Sea Surface Temperature (SST) Anomaly with Disease frames and it is provided to develop a composite.

Still image of latitude axes with equator line, provided with transparency. This still image can be overlaid on top of the Sea Surface Temperature (SST) Anomaly with Disease frames and it is provided to develop a composite.

Still image of Niño 3.4 region with transparency. The coordinates of the Niño 3.4 region are: 5N-5S, 120W-170W. This still image can be overlaid on top of the Sea Surface Temperature (SST) Anomaly with Diseases frames and it is provided to develop a composite.

Still image of Niño 3.4 region with transparency. The coordinates of the Niño 3.4 region are: 5N-5S, 120W-170W. This still image can be overlaid on top of the Sea Surface Temperature (SST) Anomaly with Diseases frames and it is provided to develop a composite.

This set of frames provides the corresponding ENSO 3.4 plot timeline for the period of 2009-2018 and it includes the label Strong El Niño Period in the highlighted 2015-2016 area. The frames contain transparency so that they can be overlaid as a layer.

This set of frames provides the corresponding ENSO 3.4 plot timeline for the period of 2009-2018 and it includes the label Strong El Niño Period in the highlighted 2015-2016 area. The frames contain transparency so that they can be overlaid as a layer.

This set of frames provides the corresponding ENSO 3.4 plot timeline for the period of 2009-2018. The frames contain transparency so that they can be overlaid as a layer.

This set of frames provides the corresponding ENSO 3.4 plot timeline for the period of 2009-2018. The frames contain transparency so that they can be overlaid as a layer.

This set of frames provides the corresponding Dates Layer for the period of 2009-2018. Frames are provided with transparency.

This set of frames provides the corresponding Dates Layer for the period of 2009-2018. Frames are provided with transparency.

Sea Surface Temperature (SST) Anomaly colorbar.

Sea Surface Temperature (SST) Anomaly colorbar.



Credits

Please give credit for this item to:
NASA's Scientific Visualization Studio

Release date

This page was originally published on Thursday, January 9, 2020.
This page was last updated on Wednesday, November 15, 2023 at 12:14 AM EST.


Papers used in this visualization

Anyamba, A., Chretien, J-P., Britch,S.C.,Soebiyanto, R.P., Small, J. L., Jepsen, P., Forshey, B.M., Sanchez, J.L., Smith, R.D., Harris, R., Tucker, C.J., Karesh, W.B., Linthicum, K.J. (2019). Global Disease Outbreaks Associated with the 2015-2016 El Niño Event. Nature Scientific Reports. 9:1930 | 10.1038/s41598-018-38034-z
