NASA-USDA-FAS Soil Moisture / IMERG
-
- Visualizations by:
- Trent L. Schindler
-
- Scientific consulting by:
- John D. Bolten
-
- Produced by:
- Matthew Radcliff
- View full credits
This visualization shows the correlation and lag time of surface soil moisture following precipitation events over Australia, India, and the United States. It uses the new NASA-USDA-FAS Soil Moisture product, a joint effort of NASA and the USDA Foreign Agricultural Service, and the global Integrated Multi-satellitE Retrievals for GPM (IMERG) precipitation dataset, which provides rainfall rates for the entire world every thirty minutes. This animation shows the 30-minute rainfall product, while the soil moisture data is a three-day moving average. Anomaly data is expressed as a standardized anomaly, e.g. (value-average)/stdev, and as such is unitless.
For more detailed information about the soil moisture product:
http://www.pecad.fas.usda.gov/cropexplorer/description.aspx?legendid=355
Bolten, J. D., W. T. Crow, T. J. Jackson, X. Zhan, and C. A. Reynolds (2010), Evaluating the utility of remotely-sensed soil moisture retrievals for operational agricultural drought monitoring, IEEE J. Sel. Topics Appl. Earth Obs., 3(1), 57–66.
For More Information
Credits
Please give credit for this item to:
NASA's Scientific Visualization Studio
-
Visualizers
- Trent L. Schindler (USRA) [Lead]
- Horace Mitchell (NASA/GSFC)
-
Scientists
- John D. Bolten (NASA/GSFC) [Lead]
- Dalia B Kirschbaum (NASA/GSFC)
- Iliana E. Mladenova (University of Maryland)
-
Producer
- Matthew Radcliff (KBR Wyle Services, LLC) [Lead]
Datasets used in this visualization
-
IMERG
ID: 863This dataset can be found at: http://pmm.nasa.gov/sites/default/files/document_files/IMERG_ATBD_V4.4.pdf
See all pages that use this dataset -
NASA-USDA-FAS Soil Moisture (Surface Soil Moisture corrected with SMOS imagery and assimilated by the Ensemble Kalman Filter)
ID: 954The surface soil moisture product is corrected by integrating satellite-derived Soil Moisture Ocean Salinity (SMOS) mission surface soil moisture retrievals into the modified Palmer two-layer soil moisture model. The SMOS imagery helps to correct the modified Pal
See all pages that use this dataset
Note: While we identify the data sets used in these visualizations, we do not store any further details, nor the data sets themselves on our site.
