Sun  ID: 3551

The Coronal Mass Ejection strikes the Earth!

This visualization is the sequel to animation ID 3867.

The CME we saw before continues to expand from the Sun, and its outer boundary is approaching the Earth. Will the Earth be pummeled like its sister planet, Venus?

Not this time, for the Earth has a fairly strong geomagnetic field.

The geomagnetic field helps deflect the incoming blast of solar particles around the Earth, dramatically reducing the impact of the event.

It is important to note that the flowing material of the CME are actually ions and electrons far too small to see. This visualization tries to represent the motions of these tiny particle in a form large enough for us to see.

Technical Details

This is the dome show component where the CME strikes the Earth.

The domemaster format was created by rendering 7 separate camera tiles. The tiles were then stitched together to form final domemaster layers at 4096x4096 resolution and 16 bits per channel with premultiplied alpha and no gamma correction. There are 2 domemaster layers that should be composited as follows:

- Earth, Sun and particles

- star field (no alpha channel)

In addition to the final domemaster frames and movies, the individual camera tiles are included as well. Each domemaster layer has a set of camera tiles. There are 7 cameras numbered 00 through 06 that represent the itiles. Camera 00 is in the center of the domemaster, camera 01 is looking below camera 00, cameras 01 through 06 look around the outside of the dome master in counter-clockwise order. These frames are probably only useful if a better re-stitching algorithm is ever required to be run on the tiles.



Visualization Credits

Greg Shirah (NASA/GSFC): Lead Animator
Horace Mitchell (NASA/GSFC): Animator
Tom Bridgman (GST): Animator
Please give credit for this item to:
NASA/Goddard Space Flight Center Scientific Visualization Studio

Short URL to share this page:

Data Used:
Enlil Heliospheric Model also referred to as: Enlil Heliospheric Model
Model - Community Coordinated Modeling Center (CCMC)
MHD solar wind simulation
BATS-R-US Magnetosphere Model
Model - Community Coordinated Modeling Center (CCMC)
MHD Magnetospheric simulation
Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.
