Chesapeake Bay Cities

This animation takes us on a tour around the Chesapeake Bay region visiting major city centers in the surrounding states: Maryland, Virginia, Delaware and the District of Columbia. The imagery utilized for this animation is a false-color Chesapeake Bay Landsat-7 Mosaic (#3473) composed of eight scenes acquired between 1999-2002, which were put together and color corrected to resemble natural looking colors.

The mosaic was created by EarthSat under contract with NASA as part of the GeoCover 2000 product. All images used in GeoCover were acquired by Landsat 7 during the period of 1999-2002. The pixel size of the full resolution image represents 14.25 m on the ground. The Chesapeake Bay mosaic uses portions of eight Landsat-7 scenes. Below you will find a listing of the eight Landsat 7 images that were put together to create the composite image. Landsat scenes are organized by a Path and Row number according to the Worldwide Reference System. (To learn more about Landsat's Worldwide Reference System, please visit: http://landsat.gsfc.nasa.gov/about/wrs.html)

Scenes used in the Chesapeake Bay mosaic: Landsat 7 WRS Path 15-Row 32 acquired on Oct. 05, 2001 Landsat 7 WRS Path 14-Row 32 acquired on Sept. 23, 1999 Landsat 7 WRS Path 15-Row 33 acquired on October 05, 2001 Landsat 7 WRS Path 14-Row 33 acquired on July 10, 2001 Landsat 7 WRS Path 15-Row 34 acquired on Sept. 30, 1999 Landsat 7 WRS Path 14-Row 34 acquired on July 10, 2001 Landsat 7 WRS Path 15-Row 35 acquired on Sept. 30, 1999 Landsat 7 WRS Path 14-Row 35 acquired on Sept. 23, 1999


Visualization Credits

Helen-Nicole Kostis (UMBC): Lead Animator
Greg Shirah (NASA/GSFC): Animator
Cindy Starr (GST): Visualizer
Lori Perkins (NASA/GSFC): Animator
Andrew Freeberg (NASA/GSFC): Producer
Darrel Williams (NASA/GSFC): Scientist
Laura Rocchio (Science Systems and Applications Inc. (SSAI)): Scientist
Please give credit for this item to:
NASA/Goddard Space Flight Center Scientific Visualization Studio

Short URL to share this page:
http://svs.gsfc.nasa.gov/3493

Mission:
Landsat

Data Used:
Landsat-7/ETM+ 1999-2002
METEOSAT-6/MVIRI/Cloud Cover
Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.
