Planets and Moons  ID: 30978

Seeing Titan with Infrared Eyes

These six infrared images of Saturn's moon Titan represent some of the clearest, most seamless-looking global views of the icy moon's surface produced so far. The views were created using 13 years of data acquired by the Visual and Infrared Mapping Spectrometer (VIMS) instrument on board NASA's Cassini spacecraft. The images are the result of a focused effort to smoothly combine data from the multitude of different observations VIMS made under a wide variety of lighting and viewing conditions over the course of Cassini's mission.

Any full color image is comprised of three color channels: red, green and blue. Each of the three color channels combined to create these views was produced using a ratio between the brightness of Titan's surface at two different wavelengths (1.59/1.27 microns [red], 2.03/1.27 microns [green] and 1.27/1.08 microns [blue]). This technique (called a "band-ratio" technique) reduces the prominence of seams, as well as emphasizing subtle spectral variations in the materials on Titan's surface. For example, the moon's equatorial dune fields appear a consistent brown color here. There are also bluish and purplish areas that may have different compositions from the other bright areas, and may be enriched in water ice.


Related


For More Information

https://photojournal.jpl.nasa.gov/catalog/PIA21923


Credits

Marit Jentoft-Nilsen: Technical Support
Please give credit for this item to:
NASA/JPL-Caltech/University of Nantes/University of Arizona

Short URL to share this page:
https://svs.gsfc.nasa.gov/30978

Mission:
Cassini-Huygens

Data Used:
Cassini/VIMS/Infrared
Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.
