The NOAA Coral Reef Watch program's satellite data provide current reef environmental conditions to quickly identify areas at risk for coral bleaching, where corals lose the symbiotic algae that give them their distinctive colors. If a coral is severely bleached, disease and partial mortality become likely, and the entire colony may die.
The satellite data used to create these products includes the polar orbiters Suomi-NPP/VIIRS and MetOp-B/AVHRR, and the geostationary satellites MSG-3, MTSAT-2, GOES-East, and GOES-West.
The NOAA Coral Reef Watch (CRW) daily 5-km satellite coral bleaching Degree Heating Week (DHW) product presented here shows accumulated thermal stress, which can lead to coral bleaching and death. The scale goes from 0 to 20 °C-weeks. The DHW product accumulates the instantaneous bleaching thermal stress (measured by Coral Bleaching HotSpots) during the most-recent 12-week period. It is directly related to the timing and intensity of coral bleaching. Significant coral bleaching usually occurs when DHW values reach 4 °C-weeks. By the time DHW values reach 8 °C-weeks, widespread bleaching is likely and significant mortality can be expected.
The NOAA Coral Reef Watch (CRW) daily 5-km Coral Bleaching HotSpot product presented here measures occurrence and magnitude of instantaneous thermal stress, potentially resulting in coral bleaching. The scale goes from 0 to 5 °C. HotSpot values of 1 °C or more indicate thermal stress leading to coral bleaching and are highlighted in yellow to dark red/brown colors.
For More Information
Credits
Please give credit for this item to:
NOAA Coral Reef Watch
-
Animator
- Marit Jentoft-Nilsen (None) [Lead]
Papers
This visualization is based on the following papers:- Liu, G.; Heron, S.F.; Eakin, C.M.; Muller-Karger, F.E.; Vega-Rodriguez, M.; Guild, L.S.; De La Cour, J.L.; Geiger, E.F.; Skirving, W.J.; Burgess, T.F.R.; Strong, A.E.; Harris, A.; Maturi, E.; Ignatov, A.; Sapper, J.; Li, J.; Lynds, S. Reef-Scale Thermal Stress Monitoring of Coral Ecosystems: New 5-km Global Products from NOAA Coral Reef Watch. Remote Sens. 2014, 6, 11579-11606.
Datasets used in this visualization
Suomi NPP VIIRS (Collected with the VIIRS sensor)
MetOp-B (Collected with the AVHRR sensor)
Meteosat-10 MSG-3 (Collected with the SEVIRI sensor)
MTSAT-2 Himawari-7 (Collected with the Imager sensor)
GOES-13/N GOES-East (Collected with the Imager sensor)
GOES-15/P GOES-West (Collected with the Imager sensor)
Note: While we identify the data sets used in these visualizations, we do not store any further details, nor the data sets themselves on our site.
