Daily Antarctic Sea Ice, By Year

  • Released Tuesday, January 17, 2023

This visualization shows the daily Antarctic sea ice and seasonal land cover change progressing through time, with a single frame rendered for each day (available from the drop-down of each image window), and an animation created from these frames.

The Japan Aerospace Exploration Agency (JAXA) provides many water-related products derived from data acquired by the Advanced Microwave Scanning Radiometer 2 (AMSR2) instrument aboard the Global Change Observation Mission 1st-Water "SHIZUKU" (GCOM-W1) satellite. Two JAXA datasets are used in this animation: the 10-km daily sea ice concentration and the 10 km daily 89 GHz Brightness Temperature.

In this visualization sea ice changes from day to day, with the amount of ice shown being determined by the AMSR2 sea ice concentration data. A running 3-day minimum is used, with a minimum threshhold concentration of 15%. The blueish white color of the sea ice is derived from a 3-day running minimum of the AMSR2 89 GHz brightness temperature. Over the terrain, monthly data from the seasonal Blue Marble Next Generation fades slowly from month to month.

The numerical portion of the frame filename begins with the four-digit year, followed by the three-digit day of the year for that frame.

2023 date frames, for compositing

2023 date frames, for compositing

2022 date frames, for compositing

2022 date frames, for compositing

2021 date frames, for compositing

2021 date frames, for compositing



Credits

Please give credit for this item to:
NASA's Scientific Visualization Studio

Release date

This page was originally published on Tuesday, January 17, 2023.
This page was last updated on Sunday, June 30, 2024 at 5:35 PM EDT.


Datasets used in this visualization

Note: While we identify the data sets used in these visualizations, we do not store any further details, nor the data sets themselves on our site.
