Sea Ice Maximum extent 2018

  • Released Friday, March 23, 2018
  • Updated Monday, February 3, 2020 at 1:26PM
  • ID: 4628

This visualization shows the Arctic sea ice as it expands from October 1, 2017 to its annual maximum extent that occurred on March 17th, 2018.
This video is also available on our YouTube channel.

Sea ice in the Arctic grew to its annual maximum extent on March 17, 2018, joining 2015, 2016, and 2017 as the years with the lowest maximum extents on record, according to scientists at the National Snow and Ice Data Center (NSIDC) and NASA. The Arctic sea ice cover peaked at 5.59 million square miles (14.48 million square kilometers), making it the second lowest maximum on record, at about 23,000 square miles (60,000 square kilometers) higher than the record low maximum reached on March 7, 2017.

This animation runs from October 1, 2017 to March 17, 2018, the date that the maximum sea ice extent occurred. The images shown here portray the sea ice as it was observed by the AMSR2 instrument onboard the Japanese Shizuku satellite. The opacity of the sea ice shown in this animation is derived from the AMSR2 sea ice concentration. The blueish white color shown on the sea ice is derived from the AMSR2 89 GHz brightness temperature data.
This image shows the maximum extent of the Arctic sea ice that occurred on March 17th, 2018.  The yellow line indicates the 30 year average maximum extent calculated from 1981 through 2010. The date is shown in the upper left corner.

This image shows the maximum extent of the Arctic sea ice that occurred on March 17th, 2018. The yellow line indicates the 30 year average maximum extent calculated from 1981 through 2010. The date is shown in the upper left corner.

The above visualization without dates.

This image shows the maximum extent of the Arctic sea ice that occurred on March 17th, 2018. The yellow line indicates the 30 year average maximum extent calculated from 1981 through 2010. On this image, the date is not displayed.

This image shows the maximum extent of the Arctic sea ice that occurred on March 17th, 2018.  The date is not displayed.

This image shows the maximum extent of the Arctic sea ice that occurred on March 17th, 2018. The date is not displayed.

Dates with transparency that correspond to the above visualization.

Dates with transparency that correspond to the above visualization.



Credits

Please give credit for this item to:
NASA's Scientific Visualization Studio

The Blue Marble data is courtesy of Reto Stockli (NASA/GSFC).


Datasets used in this visualization

SHIZUKU (GCOM-W1) 10 km Daily 89 GHz Brightness Temperature (Collected with the AMSR2 sensor)
Observed Data | Japan Aerospace Exploration Agency

Credit: AMSR2 data courtesy of the Japan Aerospace Exploration Agency (JAXA).

See more visualizations using this data set
SHIZUKU (GCOM-W1) 10 km Daily Sea Ice Concentration (Collected with the AMSR2 sensor)
Observed Data | Japan Aerospace Exploration Agency

Credit: AMSR2 data courtesy of the Japan Aerospace Exploration Agency (JAXA).

See more visualizations using this data set
Terra and Aqua BMNG (A.K.A. Blue Marble: Next Generation) (Collected with the MODIS sensor)

Credit: The Blue Marble data is courtesy of Reto Stockli (NASA/GSFC).

Dataset can be found at: http://earthobservatory.nasa.gov/Newsroom/BlueMarble/

See more visualizations using this data set
Greenland Mass Conservation Dataset - Surface Elevation
Data Compilation | Ice Sheet Modeling Group, UC, Irvine
GTOPO30 Topography and Bathymetry
Data Compilation | USGS

Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.
