Io in Motion

Io is the most volcanically active body in the Solar System. Volcanoes erupt massive volumes of silicate lava, sulphur and sulphur dioxide, constantly changing Io's appearance. This new basemap of Jupiter's moon Io was produced by combining the best images from both the Voyager 1 and Galileo Missions. Although the subjovian hemisphere of Io was poorly seen by Galileo, superbly detailed Voyager 1 images cover longitudes from 240 W to 40 W and the nearby southern latitudes. A monochrome mosaic of the highest resolution images from both Galileo and Voyager 1 was assembled that includes 51 Voyager 1 images with spatial resolutions sometimes exceeding the 1 km/pixel scale of the final mosaic. Because this mosaic is made up of images taken at various local times of day, care must be taken to note the solar illumination direction when deciding whether topographic features display positive or negative relief. In general, the illumination is from the west over longitudes 40 to 270 W, and from the east over longitudes 270 W to 40 W. Color information was later superimposed from Galileo low phase angle violet, green, and near-infrared (756 nanometer wavelength) images. The Galileo SSI camera's silicon CCD was sensitive to longer wavelengths than the vidicon cameras of Voyager, so that distinctions between red and yellow hues can be more easily discerned. The "true" colors that would be visible to the eye are similar but much more muted than shown here. Image resolutions range from 1 to 10 km/pixel along the equator, with the poorest coverage centered on longitude 50 W.

For More Information

http://photojournal.jpl.nasa.gov/catalog/PIA09257


Credits

Mark Malanoski (GST): Lead Animator
Please give credit for this item to:
NASA's Goddard Space Flight Center

Short URL to share this page:
http://svs.gsfc.nasa.gov/30706

Missions:
Galileo
Voyager

Data Used:
Voyager-1/Imaging Science Subsystem
Galileo/Solid-State Imaging Camera
Note: While we identify the data sets used in these visualizations, we do not store any further details nor the data sets themselves on our site.
