HST SM4 ACS Repair EVA
-
- Visualizations by:
- Bob Sauls
- View full credits
Advanced Camera for Surveys (ACS) produced many of the most popular and dramatic images from the Hubble Space Telescope over the last few years, but in January 2007 the instrument had a serious power failure which caused the three observing channels, the Wide Field Channel, The Solar Blind Channel and the High Resolution channel, to cease operation. The Solar Blind Channel was returned to service in February 2007. This animation shows how the Servicing Mission 4 astronauts will attempt to repair the Advanced Camera for Surveys by replacing the CCD electronics box in the Wide Field Channel and power this box with a replacement low voltage power supply. If this repair is successful, ACS will again provide the most sensitive images available at visible and near-infrared wavelengths.
Credits
Please give credit for this item to:
NASA Goddard Space Flight Center
-
Animator
- Bob Sauls (Frassanito and Associates) [Lead]
-
Producer
- Michael McClare (KBR Wyle Services, LLC)
Series
This visualization can be found in the following series:Datasets used in this visualization
-
HST
ID: 655Wide-Field Planetary Camera 2 (WFPC2) was installed in Dec 1993 and used to obtain high resolution images of astronomical objects. This camera was removed in the last servicing mission so it is no longer in service.
This dataset can be found at: http://www.stsci.edu/hst/wfpc2/wfpc2_diag.html
See all pages that use this dataset
Note: While we identify the data sets used in these visualizations, we do not store any further details, nor the data sets themselves on our site.
